Standart Cool Travego, Tourismo, 403 technical information


New TRAVEGO
Travego, Tourismo, 403 technical information 10big8wakg9
ONE TO BE 2 with AKS AKS with Module 3 is
Engine Specifications + Performance
Cylinder volume of 15,930 cc
Torque 2100 Nm / 1080 rpm
Engine type OM 502 LA
Maximum Power 476 PS DIN (350 kW) / 2000 rpm
Euro III emission norms
Gearbox Features
Transmission Mercedes-Benz GO 210 - 6/6.5virgul oil-cooled
6 +1 gear number

Suspension Geometry
Brakes front and rear axle disc brakesvirgul dual circuitvirgul dry compressed
EBS (Electronic Brake System)
BA (Brake Assist System)
ESP (Electronic Stability System)
ABSvirgul ASR
Front axle ZF RL 75 Evirgul independent suspension system. 2 Air-blowervirgul 2 absorbersvirgul stabilizer.
Rear axle MB HO6 / 1DCL (S) - 13virgul hydraulic control is active. 4 air bellowsvirgul 4 absorbers
Bonds for 3583
Steering ZF 8098virgul hydraulicvirgul height and angle adjustment
The parking brake control with compressed airvirgul effective rear axle
VOITH Retarder R 115 Evirgul şanzumana integrated
Extra axle ZF RL 75 Avirgul 2 Air-blowervirgul 2 absorbersvirgul stabilizer
Size + Weights
Wheelbase 7110 mm / 1350 mm
Length 13,850 mm
Front Extension 2600 mm
2.750 mm Rear Extension
Overall Height 3970 mm
Width 2.550 mm
Other Features
Download removal system of bodies
Tempomat (speed limiter and stabilizer)
Rear parking sensor
54 +1 +1 seats Conditioningvirgul all seats in foot
Drivers section of air
Stewardess's seat on the left-luggage locker
The left door in the middle of the driver lies
Electrically controlled - driver resistance glass
For an emergency backup mirror
Safety main switch
Blaupunkt audio system, Professional Linevirgul radiovirgul cassette and CD player
TVvirgul DVD Player (DVDvirgul VCDvirgul CDvirgul MP3)virgul 15''LCD monitor front and center
Water heaters and kitchen unit buzdolaplı
Torpedo in the extra refrigerator
Can be used as emergency exit doors electric-controlled ventilation
Electrically controlledvirgul 2-piece windshield curtain
SEE THE OWNER of the AS COK STRONG MOTOR WITH TRAVEGO ASLINDA SETRA BENZER SHOW PREVIEW is for. YOU KNOW THE SAME MOTOLARI is. SO JUST BETWEEN THESE TWO SMALL BUS CHASSIS AND PRODUCTION DETAILS PEK in FOREIGN SURPLUS not FOUND DIFFERENCES


New Tourismo
Fertilization Outside Appearance
tourismo640fp4
Tourismovirgul modern look and make a difference with the line has a superior design.
Two different lengths are offered with an alternative model 15 axle Tourismo'nun 2 RHD 12:14 mvirgul 3-axle model with the 13.99 m long, 17 RHD. Both models 2virgul55 m wide and 3virgulWith a height of 62 m platform fills.
Tourismovirgul three-dimensional standing in the middle of the front grille of the Mercedes star and the surrounding extremely hot lights with a view holds.
Starting from just below the side windows side mirrors with sharp lines, combined with the characters in the elementvirgul back to the dynamic linevirgul completes the impressive exterior. Preliminary design and dynamic character of the hot elements integrated with the rear view and he deserved Tourismo'nun complete personality characteristics provides view.
Tourismovirgul Mercedes-Benz bus family is a member of the Thoroughbred
Interior Appearance
2.01 m in width and 140 mm height 2.55 m worth the increased lengthvirgul front section with its width for the driver and passengers a spacious Tourismo'da travel environment is created. And heat from the outside through large windows, plenty of light to enter without permits. Useful and extensive luggage sectionvirgul There are a lot of places for your luggage.
Travel along the new interior design Tourismo'nun gives a deep feeling of spaciousness. From the previous model is larger than 50 mm and 140 mm length of the front section has been increased. Comfortable and ergonomically designed seats and personal controlvirgul lighting can be adjusted according to demandvirgul services such as ventilation and audio equipment with a long pleasure trip turns into. Have been rearranged for greater driving comfort is further enhanced thanks to the front axle. Improved equipment located between Tourismo'nun standard air conditioning systemvirgul offers the ideal environment for your ideal trip.
Out regardless of the temperature of the journey that provides comfort in all conditions, heating and cooling systems Tourismo'nun is the standard rule. Two axle Tourismo'da 32 kW; three axles with 35 or optional 39 kW power Tourismo'da options are available. Regardless of the comfort of the driver of the passenger comfort to ensure air conditioning is optional driver is also available. Tourismovirgul The ideal climatic conditions, and to provide passengers with travel to satisfy your drive starts.
For cold drinks and kitchen unit Tourismo'da integrated into the dashboard are two refrigerators. Also in the kitchen preparing hot beverages to the passengers needed to be able to have every opportunity. Optional hardware as well as a coffee machine may be added.
__________________
www.modpark.com


7b0cf1e5b748fdbb164ab70
Alıntı ile Cevapla
Sponsored Links


  #2
Alt 12-19-2009, 11:15
muzemm - ait Kullanıcı Resmi (Avatar)
YÖNETİCİ

Üyelik tarihi: Oct 2009
Mesajlar: 537
Tecrübe Puanı: 10
muzemm is on a distinguished road
Standart Cevap: Cool Travego, Tourismo, 403 technical information


Road King 0403
85020252
Technical information

Motor
Type OM 457 LAvirgul Turbo-Intercoolervirgul EURO3
Bore / Stroke 128 mm x 155 mm
Volume of 11,967 cm3
Max. Power 422 PS DIN (310 kW) / 2000 rpm
Max. Moment Rotation 1virgul900 Nm / 1000 to 1600 giants / dakSoğutma electromagnetic clutchvirgul 3 stage with fans
Fuel System PLDvirgul independent pump for each cylinder
Transmission
Type MB GO 190 - 6/8.2virgul oil-cooled
Number 6 +1 gear
Transfer Rate 1 2 3 4 5 6 R
8.17 4.65 2.79 1.85 1.25 1 7.683
Front Axle
Type MB VO 4 / 21 CLE 6.6
Suspension 2 air bellowsvirgul 2 absorbersvirgul stabilizer
Capacity 6600 kg
Rear Axle
Type MB HO6 / 1 DCL (S) - 13
Suspension 4 air bellowsvirgul 4 absorbersvirgul stabilizer
Capacity 13virgul000 kg
3077 Transfer Rate
Other Features
Clutch MFZ 430virgul single dry discvirgul hydraulicvirgul lining wear adjustment
Steering MB LS 6virgul hydraulicvirgul height and angle adjustment
Tank 540 ltvirgul heated water separator filter

Brakes
Dual circuit service brakevirgul dry airvirgul automatic brake linings wear
setvirgul front and rear disc brakes
Hand Brake Rear hinder effectivevirgul spread should establish
Engine Brake Standard (fifth valve)
ABSvirgul ASR Standard
Voith retarder R 115 Evirgul şanzumana integrated
Tires and Wheels (6 +1 units)
Jant 8:25 x 22.5
Tires 295/80 R 22.5
Dimensions and Weights
Length 12virgul000 mm
Width 2virgul500mm
Maximum height 3virgul583 mm
Wheelbase 6virgul250mm
Front Extension 2virgul595 mm
Rear Extensions 3virgul135 mm
Interior Height 2virgul010 mm
Number of seats 46 +1 +1 (WC to 44 +1 +1)
Maximum Loaded Weight 17virgul999 kg

Standard Equipment
Electrically controlled and heated side mirrors
Electrically controlled front glass curtain
Electrically controlledvirgul heated driver's glass
Electrically controlled roof vent covers

Locked driver Fridge
Air Suspension driver's seat
Tempomat (speed limiter and stabilizer)
Tachograph
Mobile phone antenna and preparation
Classic Line Blaupunkt audio systemvirgul radio cassette player
DVD player (DVDvirgul VCDvirgul CDvirgul MP3)
Hostesses for the microphone
Front and center 2 monitors
Torpedo refrigerator in front
Mini kitchen unit and water heater Buzdolaplı
Internal communication system
Drivers in bed
Air conditioning (35,000 W coolingvirgul Heating capacity of 30,000 W)
Additional Webasto heater
Nickel plated wheel covers
Reverse gear warning voice

Optional Equipment

WC
**** lik paint
Download removal system of bodies
Alcoa Wheels
Seat foot
Rear seat cup holders tablets
Chair legs, put the (royal class seat pricing)
Recaro returnsvirgul ventilatedvirgul heated driver's seat
Imported upholstery and fabric coating
Leather seat trim
Leather top and seat recline side wicks
Comfortline seat upholstery
Lüxline seat upholstery
Over the middle door shelf package covers
Hostess lamp
Swan-neck microphone
MB star base carpet
Drivers section of air
Driver air conditioning in bed
Multi-channel headset music system
CD changer (10 CD)
